MCP39F511-E/MQ Special Function by Microchip Technology
Newer Device Available MCP39F511A
| Status: | Active |
|---|---|
| Series: | mcp39f511 |
| RoHS: | Compliant |
Where to Buy
Prices starting from US$2.59
| Distributor | Stock | ||
|---|---|---|---|
|
Newark Electronics
from US$2.80
|
76
in stock
|
Buy Now |
|
element14
from US$3.01
|
76
in stock
|
Buy Now |
|
Farnell
from US$3.40
|
76
in stock
|
Buy Now |
|
ECOM
from US$3.92
|
21
in stock
|
Buy Now |
|
Microchip Technology
from US$2.59
|
11
in stock
|
Buy Now |
|
RS
from US$2.72
|
0
in stock
|
Buy Now |
|
Avnet America
from US$2.88
|
0
in stock
|
Buy Now |
|
TME
from US$2.63
|
0
in stock
|
Buy Now |
|
|
RS Americas
from US$3.26
|
0
in stock
|
Buy Now |
|
EBV Elektronik
-
|
0
in stock
|
Buy Now |
|
Avnet Silica
-
|
0
in stock
|
Buy Now |
| Buy Now |
Features
| Power Monitoring Accuracy capable of 0.1% error across 4000:1 dynamic range |
| Active, Reactive, Apparent Power |
| Active and Reactive Energy Accumulation |
| True RMS Current, RMS Voltage |
| Line Frequency, Power Factor |
| Dedicated Zero Crossing Detection (ZCD) Pin |
| Dedicated PWM Output Pin |
| Automatic Event Pin Control through Fast Voltage Surge Detection |
| Fast Calibration Routines |
| 2-wire UART: Baud Rate up to 115.2kbps |
| 512 bytes User-accessible EEPROM through page read/write commands |
| Low-Drift Internal Voltage Reference: 10 ppm/°C typical |
| 28-lead 5x5 QFN package |
| Extended Temperature Range -40°C to +125°C |
| AEC-Q100 qualified |
Specifications
| Input Channels | 2 |
|---|---|
| Resolution | 24 |
| Pins | Packaging | 28 | QFN |
| Temp Range | -40C to +125C |
| Packing Media | Tube (73) |
Last 6 months Inventory & Pricing History
Resources
Data Sheets |
|---|
| MCP39F511 Data Sheet |
Software Libraries and Firmware |
|---|
| Power Monitor Utility (v1.4.2) |
User Guides |
|---|
| MCP39F511 Power Monitor Demonstration Board User's Guide |
| MCP39F511A Power Monitor Demonstration Board User Guide |
Environmental Information
| JEDEC Indicator | e3 |
|---|---|
| ROHS | Compliant |
| China EFUP | Compliant |
| Device Weight (g) | 0.0665 |
| Shipping Weight (kg) | 0.109589 |
| Lead Count | 28 |
| Package Type | QFN |
| Package Width or Size | 5x5x0.9mm |
| Soldering Composition | Matte Tin |
Alternative Descriptions
| Power Monitor, 1-Phase, 0.1%, Qfn-28 | Newark Electronics |
| POWER MONITOR, 1-PHASE, 0.1%, QFN-28 | element14 |
| ADC for monitoring power, single phase, 16bit, -40+125°C | ECOM |
| Single-Phase, Power-Monitoring IC with Calculation and Event Detection | Microchip Technology |
| Microchip MCP39F511-E/MQ | RS |
| Power-Monitoring IC with Calculation and Energy Accumulation 28-Pin QFN Tube | Avnet America |
| IC: power detector | TME |
| SNGL-PHASE, PWR-MONITORING IC W/ CALC & ENERGY ACCUMULATION 28 QFN 5X5X0.9MM TUB | RS Americas |
