10897120 C-Grid by Molex
2.54mm Pitch C-Grid Breakaway Header, Dual Row, Vertical, High Temperature, 12 Circuits, 0.76µm Gold (Au) Selective Plating, Tin (Sn) PC Tail Plating, 2.72mm PC Tail
| Status: | Active |
|---|---|
| Series: | - |
| RoHS: | Compliant |
| Aliases: |
10-89-7120,
0010897120, A-70280-0086 |
Where to Buy
Prices starting from US$0.48
| Distributor | Stock | ||
|---|---|---|---|
|
Newark Electronics
from US$1.19
|
219
in stock
|
Buy Now |
|
Farnell
from US$1.36
|
198
in stock
|
Buy Now |
|
RS
from US$0.95
|
0
in stock
|
Buy Now |
|
TME
from US$0.64
|
0
in stock
|
Buy Now |
|
element14
from US$0.74
|
0
in stock
|
Buy Now |
|
Conrad
from US$1.85
|
0
in stock
|
Buy Now |
|
Heilind Americas
from US$0.87
|
0
in stock
|
Buy Now |
|
|
Heilind Europe
from US$0.48
|
0
in stock
|
Buy Now |
| Buy Now |
Specifications
| Product Name | C-Grid |
|---|---|
| Application | Board-to-Board, Wire-to-Board |
Electrical |
|
|---|---|
| Current Maximum Per Contact | 3.0A |
| Voltage Maximum | 250V |
Physical |
|
|---|---|
| Breakaway | Yes |
| Circuits Loaded | 12 |
| Circuits Maximum | 12 |
| Color Resin | Black |
| Durability Mating Cycles Max | 50 |
| First Mate Last Break | No |
| Flammability | 94V-0 |
| Glow Wire Capable | No |
| Guide To Mating Part | No |
| Keying To Mating Part | No |
| Lock To Mating Part | No |
| Material Metal | Copper Alloy |
| Material Plating Mating | Gold |
| Material Plating Termination | Tin |
| Material Resin | High Temperature Thermoplastic |
| Net Weight | 0.930/g |
| Number Of Rows | 2 |
| Orientation | Vertical |
| Pcb Locator | No |
| Pcb Retention | No |
| Pcb Thickness Recommended | 1.60mm |
| Pc Tail Length | 2.79mm |
| Pitch Mating Interface | 2.54mm |
| Plating Min Mating | 0.813µm |
| Plating Min Termination | 2.032µm |
| Polarized To Mating Part | No |
| Polarized To Pcb | No |
| Shrouded | Unshrouded |
| Stackable | Yes |
| Temperature Range Operating | -40° to +105°C |
| Termination Interface Style | Through Hole |
Last 6 months Inventory & Pricing History
Alternative Descriptions
| Header Connector, pcb Mount, recept,12 Contacts, pin,0.1 Pitch, pc Tail Terminal Rohs Compliant: Yes |Molex 10-89-7120 | Newark Electronics |
| PIN HEADERS | Farnell |
| Molex 10-89-7120 PCB Header | RS |
| Connector: pin strips | TME |
| CONN, PIN HDR, 12POS, 2ROW, 2.54MM, TH | element14 |
| Molex Stiftleiste (Standard) Anzahl Reihen: 2 10897120 1 St. Bulk | Conrad |
| CGRID VT BKWY HDR 30 SAU 12CK (240/110) | Heilind Americas |
